AO1026

Energy ManagementModular Smart Power Quality AnalyzerType WM3-96• Class 0.5 (current/voltage)• 32-bit µP-based modular smart power quality analyzer• Graph display (128x64 dots)• Front size: 96x96 mm• Measurements of single phase and system variables: W, Wdmd,VA, VAdmd, PF, PFavg, V, A, An dmd (for all of them max. andmin. values). Energies: ±kWh, 4 quadrant varh measurement.• Neutral current measurement• TRMS measurement of distorted waves (voltage/current)• Current and voltage inputs with autoranging capability• 4x4-dgt instantaneous variable read-out• 4x9-dgt total energies read-out• 4x6-dgt partial energies read-out• 48 independent energy meters to be used as single,dual, multi-time energy management• Sampling rate: 10 samples/s• Harmonic distorsion analysis (FFT) up to 50th harmonicwith both graph and numerical indication (of currentand voltage)• Harmonics source detection• Optional RS232 + real time clock function with datalogging of alarm and MIN/MAX events, montly energymetering recording• Degree of protection (front): IP 65• Up to 4 optional alarm setpoints• Up to 4 optional pulse outputs• Up to 4 optional analogue outputs• Optional serial RS 422/485 output• Universal power supply: 18 to 60VAC/DC - 90 to 260 VAC/DC• MODBUS RTU, JBUS, N2 METASYS protocols (on request)Product Description32-bit µP-based smart power quality analizer with a built-in configuration key-pad.The housing is for panel mounting and ensures a degree of protection (front) of IP 65. The instrument is par-Type Selectionticularly indicated for those application where there is the need to control the power supply quality. The variables being displayed are more than 400.Ordering Key WM3-96AV53H XX XX XX XX XModel Range code SystemPower supplySlot A Slot B Slot C Slot D OptionsRange codeAV5: 240/415 VAC -1/5 AAC(max. 300 V (L-N)/520 V (L-L) - 6 A) (standard)AV7: 400/690VAC -1/5 AAC(max. 480V (L-N) /Slot A (signal retransmission)XX: NoneA1: Single analogue output,20mADC (standard)A2: Single analogue output,±5mADC 1)A3: Single analogue output,±10mADC 1)A4: Single analogue output,1)Slot B (communication)XX: NoneB1: Dual analogue output,20mADC(standard)B2: Dual analogue output,±5mADC 1)B3: Dual analogue output,±10mADC 1)B4: Dual analogue output,1)Slot C (alarm or pulse out)XX: NoneR1: Single relay output, (AC1-8AAC, 250VAC) 1)R2: Dual relay output,(AC1-8AAC, 250VAC) 1)O1: Single open collector output (30V/100mADC) 1)O2: Dual open collector out-1)830 V (L-L) / 6 A 1)B1:±20mADCDual analogueoutput,±20mADCW1:Dual analogue output,put (30V/100mADC)D1: 3 digital inputs 1)System20mADC(standard)B2: Dual analogue output,±5mADC 1)10VDC (standard)W2:Dual analogue output,±1VDC1)Slot D (alarm or pulse out)3:One phase, three-B3: Dual analogue output,±10mADC1)W3:Dual analogue output,±5VDC1)phase system(3 or 4 wires, balan- ced load)Three phase system (3 or 4 wires, unba- lanced load)Power supplyB4: Dual analogue output,±20mADC 1)V1: Single analogue output,10VDC (standard)V2: Single analogue output,±1VDC 1)V3: Single analogue output,±5VDC 1)W4:Dual analogue output,±10VDC1)S1: Serial port,RS485 multidrop, bidirectional 1)Note:XX: NoneR2: Dual relay output,(AC1-8AAC, 250VAC) 1)O2: Dual open collector out- put (30V/100mADC) 1)O4: 4open collector out- puts (30V/100mADC) 1)V4: Single analogue output,±10VDC1)Slot A + Slot BMax 4 analogue outputsOptionsL: 18 to 60VAC/DC 1)H: 90 to 260VAC/DC1) On requestW1:Dual analogue output,10VDC (standard)W2:Dual analogue output,±1VDC 1)W3:Dual analogue output,±5VDC 1)W4:Dual analogue output,±10VDC1)Slot C + Slot Dmax 4 digital outputsX: NoneS: Serial RS232 + RTC N: With N2 Metasys protocol C:options: S+NSpecifications are subject to change without noticeWM3-96DS03031
