CLG-60-48
CLG-60-48 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with PFC, Output 48VDC / 1.3A
$0.00米ドル
4672 在庫あり
主な仕様
名前:CLG-60-48
州:Do not Use for New Designs
形式:Box
シリーズ:CLG-60
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | CLG-60-48 |
| 州 | Do not Use for New Designs |
| 形式 | Box |
| シリーズ | CLG-60 |
| 承認 | CCC, CE, PSE, UL |
| 電力（W） | 62,40 |
| サブフォーマット | IP67 |
| 幅（mm） | 61.50 |
| 高さ（mm） | 38.80 |
| AC入力最大 | 295,00 |
| AC入力最小 | 90,00 |
| アプリケーション | Lighting |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.750,00 |
| ピーク電力（W） | 62.4 |
| 入力コネクタ | Cable |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 195.60 |
| 長い説明 | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range90-295Vca47-63Hz.Output in constant current1300mA.Range of output voltage with current mode constant33,6 @ 48vdcaccording to demand load.Power:62,4 W.Efficiency typical:Eighty nine%.Input class I with grounding.Factor corrector, power>0.9to 230vac at full load.Operating temperature range of caseTcfrom-30ºCup+70ºC.Dimensions (Length x Width x Height):195,6 x 61,5 x 38,8 mm3 years of warranty.Manufacturer: MEAN WELL.The series CEN are LED Drvers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.You can also work in voltage mode constant giving a fixed voltage of 48V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing water-tight. The series CLG has a high reliability with active PFC. Burn test at 100% load. Suitable for applications of LED lighting, signage, mobile, and public lighting in dry environments, humid, and wet conditions . Complies with the requirements of security at the global level for lighting.Include cable approved for Europe (VDE) , Usa (UL), Korea (KC), Taiwan (BSMI) , China (CCC), Brazil (IEC 60245-4 ), Australia (RCM) and Japan (PSE). |
| 出力コネクタ | Cable |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 3,00 |
| 原産国 | China |
| 出力電流 mA | One thousand three hundred |
| 最小出力強度（mA） | 1.300,00 |
| 出力最大強度（mA） | 1.300,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver.
