CSP-3000-250
CSP-3000-250 MEANWELL AC-DC Single output enclosed power supply with PFC, Output 250VDC / 12A, remote ON/OFF
$0.00米ドル
4422 在庫あり
主な仕様
ファン（詳細）:Yes
名前（詳細）:CSP-3000-250
状態（詳細）:New
在庫（詳細）:Yes
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| ファン（詳細） | Yes |
| 名前（詳細） | CSP-3000-250 |
| 状態（詳細） | New |
| 在庫（詳細） | Yes |
| アラーム（詳細） | Output OK |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | CSP-3000 |
| 承認（詳細） | CE, CQC, EAC, UL |
| 電力（W）（詳細） | 3.000,00 |
| サブフォーマット（詳細） | Grid |
| 幅（mm）（詳細） | 177.80 |
| 高さ（mm）（詳細） | 63.50 |
| AC入力最大（詳細） | 264,00 |
| AC入力最小値（詳細） | 180,00 |
| アプリケーション（詳細） | Industrial, Instrumentation, Telecommunications |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | Power supply AC/DC |
| アイソレーション（V）（詳細） | 3.000,00 |
| 出力電圧（詳細） | 250,00 |
| ピーク電力（W）（詳細） | Three thousand |
| 入力コネクタ（詳細） | Screw-Type |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 278.00 |
| 長い説明（詳細） | Switching power supply with high output voltages.Especially designed for automation applications and industrial.Format in case of grid.Range of universal input180-264vac47-63Hz.Output voltage250Vcc. Adjustable by potentiometer (125-250Vcc).Output intensity12A. Range of output current 0-12A according to demand load.Power:3000W.Efficiency typical:To 92.5%.Factor corrector, power>0,95to 230vac and full load.Input class I with grounding.Alarm output voltage correctDC-Ok.Remote on / off.Auxiliary output12V +/-10%, 0,4 A.Function of sensing to compensate the voltage drop in the cables.Protections of temperature, fan failure, short circuit, over load, over voltage output.Trimming voltage120V (24-120V).Maximum current programmable120V (6-30A).Paralelizable with sharing of current(2+1) up to 7200W.PLO constant current. With off 3 sec.EMC class A.Working temperature: from-20up+65ºCof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:278 x 177,8 x 63.5.5 years of warranty.Manufacturer: MEAN WELL.VIDEO - DEMONSTRATION OF FUNCTIONS.The series CSP-3000 are the switching power supplies with high output voltages. highest range in the format box MEAN WELL. The most important feature of CSP-3000 is to provide a high voltage output: 120V / 250V / 400Vcc. Combined with a current limit at constant 100%, these sources are suitable for laser equipment, loading equipment and equipment for curing with ultraviolet rays.The sources CSP-3000 carry integrated the function of sensing to compensate the voltage drop on the output cables (depending on the thickness of the cable and the amount of amps, as well as the distance causes it to lose tension, compensándolo this function). Is can compensate for up to 0.5 V.Another of its characteristics is that, both the voltage and the current are programmable (PV / PC), allowing it to fit within a wide range by applying an external signal Vcc. The modulation of high-frequency can also be achieved by applying a PWM signal of 10V external, between 500Hz - 1kHz. Functions as the active exchange of current (up to 3 units), the on-off remote and an auxiliary output, greatly improve the design flexibility of the final system and the range of application, which makes the CSP-3000 is suitable for communication equipment, and centralized systems that require high power and high voltage.With protections of temperature, fan failure, short circuit, over load and output voltage.The protection against over loads is for current limiting, constant current with power off 3 sec. Have a high efficiency and auxiliary output of 12V.The series CSP-3000 is paralelizable with sharing power (2+1) up to 7200W. With maximum current programmable (6-30A) and trimming of voltage (24-120V). Have EMC Class A and are certifiedCE, UL, EAC, UL/EN62368-1. |
| 出力コネクタ（詳細） | Screw-Type |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | Taiwan |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Switching power supply with high output voltages.
