DDR-60G-24
DDR-60G-24 MEANWELL DC-DC Ultra slim Industrial DIN rail converter, Input 9-36VDC, Single Output 24VDC / 2.5A
$0.00米ドル
4761 在庫あり
主な仕様
名前:DDR-60G-24
州:New
ストック:Yes
形式:Din Rail
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | DDR-60G-24 |
| 州 | New |
| ストック | Yes |
| 形式 | Din Rail |
| シリーズ | DDR-60 |
| 承認 | EC, EAC |
| 電力（W） | 60,00 |
| サブフォーマット | Ladder |
| 幅（mm） | 52.50 |
| 高さ（mm） | 90.00 |
| 入力範囲 | 4:1 |
| アプリケーション | Building automation, Industrial, Telecommunications |
| DC入力最大 | 36,00 |
| DC入力最小 | 9,00 |
| メーカー | MEAN WELL |
| 製品タイプ | Dc/DC converters |
| 隔離（V） | 4.000,00 |
| 出力電圧 | 24,00 |
| ピーク電力（W） | Sixty |
| 範囲DC入力 | 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36 |
| 入力コネクタ | Screw-Type |
| 長文/背景 | 54.50 |
| 長い説明 | Dc/DC converter for din rail.Wide input range and operating temperature.Format type ladder to install on a Din rail.Input range9-36Vcc.Output voltage24vdc. Adjustable by potentiometer (21,6-28Vcc).Output intensity2,5 A.Range of output current 0-2,5 a according To demand load.Power:60W.Efficiency typical:91%.Requires No minimum load.Protected against reverse polarity input transistor, with automatic recovery.Protection for low input voltage.Protection against short-circuits and overloads.Reinforced insulation input-output 4000Vcc.CEM EN55032 Class B.Operating temperature range from-40ºCup+85ºC.Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth) [mm]:52,5 x 90 x 54,5.3 years warranty.Manufacturer: MEAN WELL.The converters of the series DDR-60 have a compact size with a wide input range 4 to 1. They also have a wide range of operating temperature. The entrance is protected from a failed connection of the polarity by using a transistor, which prevents any damage against a possible bad connection. They have a reinforced insulation between input and output of 4000Vcc and a very low level of electromagnetic emission, in compliance with the class B rules EN55032. These converters have been designed to install on a Din rail. The output voltage can be adjusted using a potentiometer. Provide an isolated output, and stabilized. It allows us to give an output reliable when we have an entry from a battery or from any other computer that can easily swing in addition to achieve isolation between the input and the output. Do not require minimum load.Series DDR has multiple utilities, both in the industrial sector, as in telecommunications applications. Suitable for industrial control systems, computers, semiconductor manufacturing, industrial automation, wireless networks and systems for telecom or datacom. |
| 出力コネクタ | Screw-Type |
| 保証期間（年） | 3,00 |
| 原産国 | China |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Dc/DC converter for din rail.
