ELG-200-48DA
ELG-200-48DA MEANWELL AC-DC Single output LED Driver (CV+CC) with PFC, Output 48VDC / 4.16A, Dimming with DA..
$0.00米ドル
4421 在庫あり
主な仕様
名前:ELG-200-48DA
州:Do not Use for New Designs
形式:Box
シリーズ:ELG-200-V-DA
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | ELG-200-48DA |
| 州 | Do not Use for New Designs |
| 形式 | Box |
| シリーズ | ELG-200-V-DA |
| 調光 | DALI |
| 承認 | CCC, CE, EAC, ENEC, KCC, MM, RCM, UL |
| 電力（W） | 199,60 |
| サブフォーマット | IP67 |
| 幅（mm） | 71.00 |
| 高さ（mm） | 37.50 |
| AC入力最大 | 305,00 |
| AC入力最小 | 100,00 |
| アプリケーション | Lighting |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.750,00 |
| ピーク電力（W） | 199.6 |
| 入力コネクタ | Cable |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 244.00 |
| 長い説明 | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current4,16 A.Range of output voltage with current mode constant24 to 48vdcaccording to demand load.Power:199,6 W.Efficiency typical:93%.Regulation DALI0% to 100% of the output intensity. Certificate to DALI.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):244 x 71 x 37.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series ELG are LED drivers, class I grounded. The own metal box serves to connect the ground of security. You can ask for a version with ground cable from the input (3 wires) by adding-3Y at the end of the model. For example ELG-200-48DA-3Y.You can also work in voltage mode constant giving a fixed voltage of 48V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing, waterproof to IP67. The series ELG has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US.Compatible with any system DALI. |
| 出力コネクタ | Cable |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 5,00 |
| 原産国 | China |
| 出力電流 mA | 4000, 4500 |
| 最小出力強度（mA） | 4.160,00 |
| 出力最大強度（mA） | 4.160,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver dimmable.
