ELGT-150-C1400DA
ELGT-150-C1400DA MEANWELL AC-DC Class II Single output LED Driver (CC) with PFC, Output 107VDC / 1.4A, Dimmi..
$0.00米ドル
4470 在庫あり
主な仕様
名前:ELGT-150-C1400DA
州:New
ストック:Yes
形式:Box
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | ELGT-150-C1400DA |
| 州 | New |
| ストック | Yes |
| 形式 | Box |
| シリーズ | ELGT-150-C-DA |
| 調光 | DALI |
| 承認 | CCC, CE, ENEC |
| 電力（W） | 149,80 |
| サブフォーマット | IP67 |
| 幅（mm） | 63.00 |
| 高さ（mm） | 35.50 |
| AC入力最大 | 305,00 |
| AC入力最小 | 100,00 |
| アプリケーション | Lighting |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.750,00 |
| ピーク電力（W） | 149.8 |
| 入力コネクタ | Cable |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 219.00 |
| 長い説明 | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current1400mA.Range of output voltage with current mode constant54 to 107Vccaccording to demand load.Power:149,8 W.Efficiency typical:91%.Regulation DALI0% to 100% of the output current with regulation DALI. Certificate to DALI.Class II with functional earth for EMC.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):219 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series ELGT are LED drivers, class II with functional earth for EMC. The cabinet itself has a double insulation improve the protection against lightning and transients without the use of cable earth.With metal housing, waterproof to IP67. The series ELGT has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality.Compatible with any system DALI. |
| 出力コネクタ | Cable |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 5,00 |
| 原産国 | China |
| 出力電流 mA | One thousand four hundred |
| 最小出力強度（mA） | 1.400,00 |
| 出力最大強度（mA） | 1.400,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver.
