ELN-30-24D
ELN-30-24D MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 24VDC / 1.25A, Dimming with 1-10..
$0.00米ドル
4770 在庫あり
主な仕様
名前:ELN-30-24D
州:Do not Use for New Designs
形式:Box
シリーズ:ELN-30D
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | ELN-30-24D |
| 州 | Do not Use for New Designs |
| 形式 | Box |
| シリーズ | ELN-30D |
| 調光 | 1-10V |
| 承認 | CE, UL |
| 電力（W） | 30,00 |
| サブフォーマット | IP64 |
| 幅（mm） | 47.00 |
| 高さ（mm） | 30.00 |
| AC入力最大 | 264,00 |
| AC入力最小 | 90,00 |
| アプリケーション | Industrial, Telecommunications |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.000,00 |
| ピーク電力（W） | Thirty |
| 入力コネクタ | Cable |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 145.00 |
| 長い説明 | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP64.Input range90-264vac47-63Hz.Output in constant current1250mA.Range of output voltage with current mode constant3 to 24vdcaccording to demand load.Power:30W.Eficienciatípica:85%.Regulationfrom 10% to 100% of the output intensity with a dimmer 1-10V. With the regulation we can not turn off the output, we can only go down to 10%.Input class II without grounding.Operating temperature range of caseTcfrom-20ºCup+60ºC.Dimensions (Length x Width x Height):One hundred forty fivex 47 x 30mm.2 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.You can also work in voltage mode constant giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.With plastic housing, designed for applications of LED-lighting and signalling mobile. Suitable for interior lighting and electronic displays.Can be adjusted by regulatory assets or liabilities1-10V.Compatible with any dimmer 1-10V-market both assets and liabilities. Does not work with dimmers Triac dimmer cutting phase.Some compatible models tested are:MEAN WELL DAP-04S01 (compatible with any push button normally open)SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| 出力コネクタ | Cable |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 2,00 |
| 原産国 | China |
| 出力電流 mA | One thousand two hundred fifty |
| 最小出力強度（mA） | 1.250,00 |
| 出力最大強度（mA） | 1.250,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver.
