HBGC-300-H-DA
HBGC-300-H-DA MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 58VDC / ..
$0.00米ドル
3854 在庫あり
主な仕様
名前（詳細）:HBGC-300-H-DA
状態（詳細）:New
フォーマット（詳細）:Box
シリーズ（詳細）:HBGC-300-DA
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | HBGC-300-H-DA |
| 状態（詳細） | New |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | HBGC-300-DA |
| 承認（詳細） | CCC, CE, EAC, ENEC, KCC, UL |
| 電力（W）（詳細） | 301,60 |
| 規制（詳細） | DALI, DALI 2 |
| サブフォーマット（詳細） | IP67 |
| 幅（mm）（詳細） | 191.5 |
| 高さ（mm）（詳細） | Sixty nine |
| AC入力最大（詳細） | 305,00 |
| AC入力最小値（詳細） | 90,00 |
| アプリケーション（詳細） | Lighting |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | LED Driver |
| アイソレーション（V）（詳細） | 3.750,00 |
| ピーク電力（W）（詳細） | 301.6 |
| 入力コネクタ（詳細） | Cable |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 191.5 |
| 長い説明（詳細） | LED driver dimmable with constant power.Specially designed for powering LEDs directly in a steady stream.Format circular metal patentedIP67.Input range90-305Vca47-63Hz.Output in constant current5,6 A.Adjustable by external potentiometer (2,6-8,67 (A).Maximum output power rating of between5,2-8,67 To.Range of output voltage with current mode constant29 to 58Vccaccording to demand load and according to adjustment of the output current.Power:Eur 301.6 W.Efficiency typical:To 92.5%.Regulation by DALI2.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+80ºC.Dimensions (Diameter x Height):191,5 x 69mm.5 years of warranty.Manufacturer: MEAN WELL.The series HBGC-300-H-DA are LED drivers with constant power. Give an output constant current which can be adjusted by DALI2 and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.This version GIVES you have regulation by DALI2.The series HBGC are LED drivers, class I grounded.With housing circular metal patented IP67. The series HBGC-300 is specially designed for the bells and LED spotlights, scenarios, and bays. Intended for applications in dry, damp or wet, both in exterior and in interior.Compatible with any system DALI and DALI2. |
| 出力コネクタ（詳細） | Cable |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | China |
| 出力電流 mA (詳細) | 2600, 2700, 2800, 2900, 3000, 3100, 3200, 3300, 3400, 3500, 4000, 4500, 5000, 5500, 6000, 7000, 8000, 9000 |
| 最小出力強度（mA）（詳細） | 2.600,00 |
| 出力最大強度（mA）（詳細） | 8,670 grant,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver dimmable with constant power.
