HDFKV 95-F-VP T45
HDFKV 95-F-VP T45 1712236 PHOENIX CONTACT Panel feed-through terminal block
$0.00米ドル
4242 在庫あり
主な仕様
:• Observe the technical data provided here and refer to the documents listed under “Downloads”. The download area contains important information, such as installation notes, technical drawings, and 3D data.
ピッチ:25 mm
色 （）:()
安全に関する注意事項:• Only electrically qualified personnel may install and operate the product.To recognize and prevent danger, the qualified personnel must be familiar with the basics of electrical engineering.
サプライヤー情報
製品: 0
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| • Observe the technical data provided here and refer to the documents listed under “Downloads”. The download area contains important information, such as installation notes, technical drawings, and 3D data. | |
| ピッチ | 25 mm |
| 色 （） | () |
| 安全に関する注意事項 | • Only electrically qualified personnel may install and operate the product.To recognize and prevent danger, the qualified personnel must be familiar with the basics of electrical engineering. |
| 製品タイプ | Panel feed-through terminal block |
| 製品ファミリー | HDFKV 95-VP |
| 接続方法 | Screw connection with tension sleeve |
| 公称電流IN | 232 A |
| 汚染度 | 3 |
| 寸法図 | |
| 断熱材 | PA |
| 申請に関する注意事項 | To maintain the nominal voltage, align the cable lugs straight and centered, and cast the terminals on the inside. |
| ポジション数 | 1 |
| 潜在的な数 | 1 |
| 接続数 | 2 |
| 導体の接続方向とプラグイン方向 | -90 ° |
製品説明
Panel feed-through terminal block, connection method: Screw connection with tension sleeve, Cable lug connection, number of positions: 1, load current: 232 A, connection direction of the conductor to
