HLG-40H-24

技術仕様

パラメータ	価値
名前	HLG-40H-24
州	Recommended Model
形式	Box
シリーズ	HLG-40H
承認	CCC, CE, EAC, KCC, MM, PSE, RCM, TUV, UL
電力（W）	40,00
サブフォーマット	IP67
幅（mm）	61.50
高さ（mm）	36.80
AC入力最大	305,00
AC入力最小	90,00
アプリケーション	Lighting
メーカー	MEAN WELL
製品タイプ	LED Driver
隔離（V）	3.750,00
出力電圧	24,00
ピーク電力（W）	Forty
入力コネクタ	Cable
入力周波数	50 Hz, 60 Hz
長文/背景	171.00
長い説明	LED driver.Specially designed to feed LED strips.Format in metal box sealedIP67.Input range90-305Vca47-63Hz.Output voltage24vdc.Output intensity1670mA. Range of output current 0-1670mA according to demand load.Power:40W.Efficiency typical:88%.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+70ºC.Dimensions (Length x Width x Height):171 x 61.5 x 36,8 mm7 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Working mode constant voltage giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.The series HLG are LED drivers, class I grounded.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.With metal housing, waterproof to IP67. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting.
出力コネクタ	Cable
入国の種類 CA	Single-phase
保証期間（年）	7,00
原産国	China

製品説明

More details

主な機能

産業グレードの品質
RoHS準拠
CE認証取得
1年保証

技術的詳細

LED driver.
