HVG-100-42D
HVG-100-42D MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 2,2A. 95,7W, 21-42V. IP67. Time..
$0.00米ドル
3287 在庫あり
主な仕様
名前（詳細）:HVG-100-42D
状態（詳細）:Requires Minimum Quantities
フォーマット（詳細）:Box
承認（詳細）:UL
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | HVG-100-42D |
| 状態（詳細） | Requires Minimum Quantities |
| フォーマット（詳細） | Box |
| 承認（詳細） | UL |
| 電力（W）（詳細） | 95,70 |
| 規制（詳細） | Smart |
| サブフォーマット（詳細） | IP67 |
| 幅（mm）（詳細） | 68.00 |
| 高さ（mm）（詳細） | 38.80 |
| AC入力最大（詳細） | 528,00 |
| AC入力最小値（詳細） | 180,00 |
| アプリケーション（詳細） | Lighting |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | LED Driver |
| アイソレーション（V）（詳細） | 3.750,00 |
| ピーク電力（W）（詳細） | 95.7 |
| 入力コネクタ（詳細） | Cable |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 236.00 |
| 長い説明（詳細） | LED driver dimmable with phase input.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input rangeEighteen0-528Vca47-63Hz.Output in constant currentTo 2.28 A.Range of output voltage with current mode constant21 to42Vccaccording to demand load.Power:95,7 W.Efficiency typical:Total of 90.5%.Regulation Smart Dimmingprogrammed at the factory.Input class I with grounding.Factor corrector, power>0,98to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):236 x 68 x 38,8 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.The series HVG are LED drivers, class I grounded.You can also work in voltage mode constant giving a fixed voltage of 42V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing IP67. The series HVG has a high efficiency designed for applications of public lighting, exterior, interior, or any application of LED lighting. Approved HL Class I Division 2 for ex-zones in the US. Complies with the requirements of security at the global level for lighting.The version D with Timer Dimming comes with the curve-regulation of the driver is programmed from the factory according to the customer's specification. Fixed a few periods and some rules of the output and the driver will always use the same curves regardless of the hours that it is turned on. We can set up between 2 and 5 different levels. You can make bends fixed on the basis of a few hours of operation. In this way we can achieve greater energy savings and adjust the brightness levels according to the level of occupation. The programming from the factory cannot be changed.In addition to this setting on the D versions is you can limit the maximum output current, for example if we use a driver 1050mA and you only need to 900mA can be adjusted to the maximum value of the output current.With the version Timer dimming can achieve energy savings most important, always maintaining a level of brightness appropriate and with a stand-alone system that enables us to avoid any maintenance cost. |
| 出力コネクタ（詳細） | Cable |
| 入国の種類 CA (詳細) | Three-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | China |
| 出力電流 mA (詳細) | 2200, 2300 |
| 最小出力強度（mA）（詳細） | 2.280,00 |
| 出力最大強度（mA）（詳細） | 2.280,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver dimmable with phase input.
