KSC-01L
KSC-01L MEANWELL KNX TP Media Coupler, Universal Plug and Play, No additional external power supply required
$0.00米ドル
3285 在庫あり
主な仕様
名前（詳細）:KSC-01L
状態（詳細）:New
フォーマット（詳細）:Din Rail
シリーズ（詳細）:KSC-01L
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | KSC-01L |
| 状態（詳細） | New |
| フォーマット（詳細） | Din Rail |
| シリーズ（詳細） | KSC-01L |
| 承認（詳細） | EC |
| サブフォーマット（詳細） | IP20 |
| 幅（mm）（詳細） | 36.00 |
| 高さ（mm）（詳細） | 90.00 |
| アプリケーション（詳細） | Building automation, Lighting |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | Coupler/signal Repeater |
| アイソレーション（V）（詳細） | 3.750,00 |
| 出力信号（詳細） | KNX |
| 入力コネクタ（詳細） | Quick Connector |
| ロング/背景（詳細） | 71.00 |
| 長い説明（詳細） | Coupler / Repeater lines KNX-PT.With function of automatic filtering of telegrams.Format ladder to install on a DIN rail. IP20.Input range21-30vdc. (KNX-PT).Input signals:KNX.Output signal:KNX.Tracking the traffic between the sublines.Manual function, functions of diagnosis and filtering of telegrams.Indicator LED for the state and the telegram traffic of the main line and the sub-line of the KNX bus-PT.KNX protocol.Supports messages of up to240 bytes.Working temperature: from-5ºCup+45 ° Cof ambient temperature.Dimensions (Length x Width x Height) [mm]:71 x 36 x 90.3 years warrantyManufacturer: MEAN WELL.The KSC-01L is a coupler means KNX-PT. It works as a device designed to attach two lines to the KNX twisted pair in conjunction with the flexibility of allowing, in the mode coupler line, both the connection of a subline KNX to a main line KNX, as a main line KNX line areas, KNX (or line backbone KNX). Or, in the repeater mode, the connection of two segments of the same subline. Segments of up to four lines, can form a single line KNX PT by connecting three repeater line of the series KSC.The model KSC-01L has a built-in function of automatic filtering of telegrams, to facilitate the implementation and resolution of problems. With manual function for the filter of telegrams of short duration, and the routing / repeat / confirmation, and special configurations available. In addition, it is available (optional) the version of secure data KNX (KSC-02L), which effectively protects the user data against access and tampering by using encryption and authentication.Format ladder to install on a DIN rail, designed for automation applications in buildings, office lighting, lighting for smart homes and luxury villas, and lighting of interior LED, |
| 出力コネクタ（詳細） | Quick Connector |
| 保証期間（年数）（詳細） | 3,00 |
| 原産国（詳細） | China |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Coupler / Repeater lines KNX-PT.
