LDD-1200L

技術仕様

パラメータ	価値
名前	LDD-1200L
州	Recommended Model
形式	Box
シリーズ	LDD-1000-1500L
調光	Analog, Signal PWM 10V
承認	EC
電力（W）	36,00
サブフォーマット	Encapsulated
幅（mm）	20.30
高さ（mm）	12.20
アプリケーション	Lighting, Solar
メーカー	MEAN WELL
製品タイプ	LED Driver
ピーク電力（W）	Thirty six
範囲DC入力	6, 6,5, 7, 8, 8,3, 9, 9,2, 10, 10,5, 10,8, 12, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 22,5, 24, 25,2, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36
入力コネクタ	Pin
長文/背景	31.80
長い説明	LED driver input and continuous output in a steady stream.Specially designed for applications of solar street lights powered from battery.Format in box with connection pins.IP67.Input rangeSix-36Vcc.Output in constant current1200mA.Range of output voltage with current mode constantTwoto 30vdcaccording to demand load.The output voltage must be at least 3V lower than the input voltage. Regulator Buck (Vout < Vin).Power:36W.Efficiency typical:95%.Regulation0% to 100% of the output intensity with a PWM signal or analog 0.5 to 2.5 V.Consumption without load 1mA in power-off mode.Operating temperature range of caseTcfrom-40ºCup+71ºC.Dimensions (Length x Width x Height):31,8 x 20,3 x 12,2 mm3 years of warranty.Manufacturer: MEAN WELL.The series LDD-L are current regulators designed to feed the leds from a battery or dc voltage. These teams can be dimmed with a PWM signal or an analog signal.This series are voltage reducers (designed for buck or step-down) that reduce the input voltage to an output voltage lower while keeping the output current constant. It is very important to consider that the supply voltage of the leds must be at least 3V lower than the supply voltage.
出力コネクタ	Pin
保証期間（年）	3,00
原産国	Taiwan
出力電流 mA	One thousand two hundred

製品説明

More details

主な機能

産業グレードの品質
RoHS準拠
CE認証取得
1年保証

技術的詳細

LED driver input and continuous output in a steady stream.
