ODLC-45-500
ODLC-45-500 MEANWELL AC-DC Constant Current mode (CC) LED driver with PFC, Input range 90-295VAC, Output 90V..
$0.00米ドル
3261 在庫あり
主な仕様
名前:ODLC-45-500
州:New
形式:Box
シリーズ:ODLC-45
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | ODLC-45-500 |
| 州 | New |
| 形式 | Box |
| シリーズ | ODLC-45 |
| 調光 | 0-10V, 1-10V, PWM Signal 10V |
| 承認 | CCC, CE, ENEC, UL |
| 電力（W） | 45,00 |
| サブフォーマット | IP67 |
| 幅（mm） | 77.00 |
| 高さ（mm） | 28.50 |
| AC入力最大 | 295,00 |
| AC入力最小 | 90,00 |
| アプリケーション | Lighting |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.750,00 |
| ピーク電力（W） | Forty five |
| 入力コネクタ | Cable |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 111.00 |
| 長い説明 | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in box waterproof plasticIP67.Input range90-295Vca47-63Hz.Output in constant current500mA.Range of output voltage with current mode constant54 to 90Vccaccording to demand load.Power:45W.Efficiency typical:85%.Regulation0% to 100% of the output intensity with a slider0-10V / 1-10Vor a PWM signal of 10V with a frequency of 100Hz to 3KHz. With the regulation we can turn off the output, but we need a regulator 0-10V. Regulators 1-10V not arrive to give 0V do not shut down the output.Input class II without grounding.Factor corrector, power>0.92to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-20ºCup+85ºC.Dimensions (Length x Width x Height):111 x 77 x 28.5 mm3 years of warranty.Manufacturer: MEAN WELL.The series ODLC are LED drivers designed to work directly with LEDs (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing, waterproof IP67, designed for lighting applications in interior and exterior. Low ripple current, no flicker (flicker-free).This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.These sources can be dimmed with dimmers assets or liabilities of0-10Vor1-10V, signal 10V PWM of 100Hz to 3KHz. Does not work with dimmers Triac dimmer cutting phase.(Not to be confused with regulators TRIACs, cutting phase. This driver cannot be regular with a Triac).With potentiometers assets that you can give 0V to shut down the output without the need of a switch. Dimmers 1-10V we can only reach 10% of regulation without shutting down the output. If you want to regular LED strips, we recommend the series ODLV or PWM.Compatible with any regulator 0-10V or 1-10V-market both assets and liabilities. Does not work with dimmers Triac dimmer cutting phase.Some compatible models tested are:MEAN WELL DAP-04-S01 (compatible with any push button normally open)SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| 出力コネクタ | Cable |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 3,00 |
| 原産国 | China |
| 出力電流 mA | Five hundred |
| 最小出力強度（mA） | 500,00 |
| 出力最大強度（mA） | 500,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver dimmable.
