PLC-30-24
PLC-30-24 MEANWELL AC-DC Single output LED driver Constant Current (CC), Output 24VDC / 1.25A, I/O screw ter..
$0.00米ドル
4648 在庫あり
主な仕様
名前:PLC-30-24
ストック:Yes
形式:Box
シリーズ:PLC-30
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | PLC-30-24 |
| ストック | Yes |
| 形式 | Box |
| シリーズ | PLC-30 |
| 承認 | CCC, CE, PSE, UL |
| 電力（W） | 24,00 |
| サブフォーマット | IP20 |
| 幅（mm） | 46.00 |
| 高さ（mm） | 30.00 |
| AC入力最大 | 264,00 |
| AC入力最小 | 90,00 |
| アプリケーション | Lighting |
| メーカー | MEAN WELL |
| 製品タイプ | LED Driver |
| 隔離（V） | 3.750,00 |
| ピーク電力（W） | Twenty four |
| 入力コネクタ | Screw-Type |
| 入力周波数 | 50 Hz, 60 Hz |
| 長文/背景 | 160.00 |
| 長い説明 | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in case of plastic encapsulated.Input range90-264vac47-63Hz.Output in constant current1250mA.Adjustable by external potentiometer (938-1288mA).Range of output voltage with current mode constantThe 16.8 to 24vdcaccording to demand load.The output voltage in voltage mode constant24vdc.Adjustable by external potentiometer (22,8-26,4 Vdc).Power:30W.Efficiency typical:84%.Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.Input class II without grounding.Factor corrector, power>0,9to 230vac at full load.Operating temperature range of caseTcfrom-30ºCup+50ºC.Dimensions (Length x Width x Height):160 x 46 x 30mm.2 years of warranty.Manufacturer: MEAN WELL.Series PLC are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. The output current and the output voltage can be adjusted byexternal potentiometerslocated in the housing of the source.With plastic casing encapsulated with lock system for input and output. Series PLC has a small and compact size with connection by screw and ventilation for free circulation of air. The active PFC and high reliability. Burn test at 100% load. Suitable for applications of LED lighting and signaling cell, in accordance with the requirements of security at the global level for lighting. |
| 出力コネクタ | Screw-Type |
| 入国の種類 CA | Single-phase |
| 保証期間（年） | 2,00 |
| 原産国 | China |
| 出力電流 mA | One thousand two hundred fifty |
| 最小出力強度（mA） | 1.250,00 |
| 出力最大強度（mA） | 1.250,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver.
