QAE150-12S24
QAE150-12S24 MEANWELL DC-DC converter. Quarter-Brick format. Input range 2-to-1. Regulated output. Isolation..
$0.00米ドル
3625 在庫あり
主な仕様
名前:QAE150-12S24
州:New
形式:For Printed Circuit
シリーズ:QAE150
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前 | QAE150-12S24 |
| 州 | New |
| 形式 | For Printed Circuit |
| シリーズ | QAE150 |
| 承認 | CE, UL |
| 電力（W） | 150,00 |
| サブフォーマット | Quarter-Brick |
| 幅（mm） | 36.8 |
| 高さ（mm） | 12.7 |
| 入力範囲 | 2:1 |
| アプリケーション | Building automation, Lighting, Industrial, Instrumentation, Telecommunications |
| DC入力最大 | 22,00 |
| DC入力最小 | 8,50 |
| メーカー | P-DUKE |
| 製品タイプ | Dc/DC converters |
| 隔離（V） | 2.250,00 |
| 出力電圧 | 24,00 |
| ピーク電力（W） | One hundred fifty |
| 範囲DC入力 | 8,4, 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 20,4, 21, 21,6, 22,5 |
| 入力コネクタ | Pin |
| 長文/背景 | 57.9 |
| 長い説明 | Dc/DC converter in the format Quarter-Brick, and input range 2-to-1. Regulated output. Isolation 2250Vcc.Converter for applications in telecommunications, industrial, distributed architecture and equipment for semiconductors.Input range:8,5-22Vcc.Output voltage:24vdc.Output intensity:5A.Power:150W.Isolation input-output 2250Vcc.Efficiency of 90%.Noise and ripple 200mVp-p.Remote on / off.Function of trrimming to adjust the output voltage from -20% and +10%.Operating temperature from -40ºC to +105ºC (case temperature). See the curve of drift in the data sheet.Dimensions (Length x Width x Height):57,9 x 36,8 x 12,7 mm. Format (Quarter-Brick, half-brick)3 years of warranty.Manufacturer: P-DUKE.Certificate CE, EN60950-1, UL60950-1, IEC60950-1, EN62368-1 and UL62368-1.The converters of the series QAE150 are converters in format industrial quarter brick quarter-brick) high reliability.They have a wide input range 2 to 1, and do not need a minimum load. The output voltage can be adjusted dynamically by using the pins trimming and also we can turn on and off the output of the converters by means of the pin remote control. They have all kinds of protections such as protection against over load, short circuit, over output voltage, low input voltage and over temperature. Have a high efficiency and a low noise and ripple.This converter does not need a minimum load, has a low ripple of output and protection against excess temperature. Have a long expected life and meet mil standards thermal shock MIL-STD-810F vibration and MIL-STD-810F.The series QAE150 is a reliable solution for almost any application. |
| 出力コネクタ | Pin |
| 保証期間（年） | 3,00 |
| 原産国 | Taiwan |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Dc/DC converter in the format Quarter-Brick, and input range 2-to-1. Regulated output. Isolation 2250Vcc.
