R88D-KN30F-ECT-L

R88L-EC-FW/GW-@Accurax linear motorNew linear motors with optimised efficiency Iron-core motors for high speed and high duty cycle operations and Ironless motors for cogging-free and high dynamic applications. Both motor and families deliver unparalleled accuracy and performance benefits.• Ironless and iron-core types available• High dynamic and precise positioning• Compact and flat design iron-core motors• Excellent force-to-weight ratio ironless motors• Weight-optimised magnet track• Optional digital hall-sensor and connectors• Temperature sensors includedRatings• Iron-core motors – 48 to 760 N (2,000 N peak force)• Ironless motors – 29 to 423 N (2,100 N peak force)System configuration(Refer to servo drive chapter)ADRAccurax G5 servo driveEtherCAT and analogue/pulse modelsHallSensorTemp. SensorPowerMotor coilR88L-EC-GW Motor coilR88L-EC-FWHallSensorTemp. SensorMagnet trackR88L-EC-FMEncoderPowerEncoderMagnet trackR88L-EC-GMIronlesslinear motorIron-core linear motorAccurax linear motor 1
