UHGS1010AC
UHGS1010AC HG-S1010-AC PANASONIC HG-S Sensor for measurement by contact. Head sensor with pneumatic actuator..
$0.00米ドル
4292 在庫あり
主な仕様
アイテム:Specifications
述べる:Where measurement conditions are not specified, the conditions used were as follows: standard type measurement probe (HG-SS10C), ambient temperature of +20 ℃+68 ℉, and a clean atmosphere where water, oil, other liquids or dust does not come in contact with the equipment.
脳卒中:10.5 mm0.413 inor more(Note) : The position that represents "0" as an absolute value is a position where the spindle is pushed further down from the bottom dead point by 0.1 mm0.004 inor more. The term "stroke" indicates the total stroke length from the bottom dead point to the top dead point.
重さ:Net weight: 80 g approx.
サプライヤー情報
PANASONIC
製品: 4316
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| アイテム | Specifications |
| 述べる | Where measurement conditions are not specified, the conditions used were as follows: standard type measurement probe (HG-SS10C), ambient temperature of +20 ℃+68 ℉, and a clean atmosphere where water, oil, other liquids or dust does not come in contact with the equipment. |
| 脳卒中 | 10.5 mm0.413 inor more(Note) : The position that represents "0" as an absolute value is a position where the spindle is pushed further down from the bottom dead point by 0.1 mm0.004 inor more. The term "stroke" indicates the total stroke length from the bottom dead point to the top dead point. |
| 重さ | Net weight: 80 g approx. |
| 詳細 | Air-driven type10 mm0.394 intype General purpose |
| 製品 | Contact-Type Digital Displacement Sensor |
| 材料 | Body: Zinc, Holder: Stainless steel, Spindle: Tool steel, Probe (Note): Brass (body) / Ceramic (ball),, Air tube clamp: S60CM(Note) : The probe is also available as an option. |
| アクセサリー | Sensor head fastening wrench: 1 pc., Mounting nut: 1 pc., Seal cap: 1pc, Air tube clamp: 1 pc. |
| 解決 | 0.5 μm0.02 mil |
| 部品番号 | HG-S1010-AC |
| 製品名 | Contact-Type Digital Displacement Sensor HG-S |
| 使用可能な流体 | Clean air (Dew point temperature: -10 ℃+14 ℉or less) |
| サンプリングレート | 1 ms |
| 製品番号 | HG-S1010-AC |
| 適用チューブ | Outside diameter: ø4 mmø0.157 in/ Inside diameter: ø2.5 mmø0.098 in |
| 力の測定 | ・Measuring force changes with the air pressure used. Removing the seal cap enables the product to be used as the low measuring force type.・For the relationship between supplied air pressure and measuring force or between measuring force and pushed spindle position, see the figures below. For upward mount without a seal cap, subtract 0.2 N from the measuring force. For side mount, subtract 0.1 N from the measuring force. The following figures are only typical examples, and these relationships differ depending on the assembly accuracy of the product or the abrasion status of sealing materials. |
| 測定範囲 | 10 mm0.394 in(Note) : The position that represents "0" as an absolute value is a position where the spindle is pushed further down from the bottom dead point by 0.1 mm0.004 inor more. The term "stroke" indicates the total stroke length from the bottom dead point to the top dead point. |
| 接地方法 | Capacitor grounding |
| 汚染度 | 2 |
| ホットスワップ機能 | Incorporated |
| 動作高度 | 2,000 m6561.68 ftor less(Note) : Do not use or store in an environment that has been pressurized to an air pressure higher than the atmospheric pressure at 0 m. |
| 操作インジケーター | Equipped (2-color LED: Orange / Green) |
| チップ偏差量 | 35 μm1.378 mil(typical value) |
| 適用可能なコントローラー | HG-SC101(-P), HG-SC111(-P), HG-SC112(-P), HG-SC113(Note) : Be sure to use the sensor in combination with an HG-SC□ controller manufactured in or after February 2019. |
| 絶縁抵抗 | 100 MΩ or more at 250 V DC |
| 規制遵守 | CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) |
| 動作圧力範囲 | 0.14 to 0.16 MPaWith no seal cap mounted : 0.035 to 0.045 MPa |
| 指示精度(PP) | Full range: 2.0 μm0.079 milor lessLimited range: 1.0 μm0.039 milor less(any 60 μm2.362 mil) |
| 位置検出方法 | Optical absolute linear encoder method |
| 圧力に耐える能力 | 0.2 MPa |
| 環境耐性：保護 | IP67 (IEC)With no seal cap mounted : -(Note) : Protective structure is not applicable when the sealing portions have deteriorated or become damaged. The protection level is zero when the seal cap is removed. |
| 耐環境性：周囲湿度 | 35 to 85 % RH, Storage: 35 to 85 % RH |
| 耐環境性：耐衝撃性 | 1,960 m/s2acceleration in X, Y, and Z directions three times each |
| 耐環境性：周囲温度 | -10 to +55 ℃+14 to +131 ℉(No dew condensation or icing allowed),Storage: -20 to +60 ℃-4 to +140 ℉ |
| 耐環境性：耐振動性 | 10 to 500 Hz frequency, 3 mm0.118 indouble amplitude (10 to 58 Hz), maximum acceleration 196 m/s2, (58 to 150 Hz) in X, Y, and Z directions for two hours each |
製品説明
HG-S - Contact measurement sensor. Sensor head with pneumatic actuator. Resolution 0.5μm. Precision 2μm. Range 10mm
