UHGT1110
UHGT1110 HG-T1110 PANASONIC HG-T Laser Sensor Displacement. Head sensor close, without adjustment indicator ..
$0.00米ドル
4730 在庫あり
主な仕様
アイテム:Specifications
ケーブル:0.2 m0.656 ft4-core shielded cable with round connectors
詳細:Measurement width 10 mm0.394 in/ Slim type
製品:Sensor heads
サプライヤー情報
PANASONIC
製品: 4316
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| アイテム | Specifications |
| ケーブル | 0.2 m0.656 ft4-core shielded cable with round connectors |
| 詳細 | Measurement width 10 mm0.394 in/ Slim type |
| 製品 | Sensor heads |
| 材料 | Case: Die-cast aluminum, Light emitting and light receiving surfaces: Glass |
| 直線性 | ±0.12 % F.S. (Installation distance: 20 mm0.787 in)±0.28 % F.S. (Installation distance: 100 mm3.937 in)(Note)Indicates an error with the ideal straight line of digital measured values. |
| 正味重量 | Emitter: 30 g approx., Receiver: 25 g approx. |
| 部品番号 | HG-T1110 |
| 光源 | Red semiconductor laser: Class 1 [IEC / EN / JIS / GB / KS / FDA](Note)This product complies with the FDA regulations (FDA 21 CFR 1040.10 and 1040.11) in accordance with FDA Laser Notice No. 56, except for complying with IEC 60825-1 Ed. 3. |
| 製品名 | Thru-beam Type Digital Displacement Sensor HG-T |
| 再現性 | 1 μm0.039 mil(Installation distance: 20 mm0.787 in)2.5 μm0.098 mil(Installation distance: 100 mm3.937 in)5 μm0.197 mil(Installation distance: 500 mm19.685 in)(Note)This is the P-P value of digital measurement value with half shading at the middle position of the installation distance. |
| 製品番号 | HG-T1110 |
| 接地方法 | Capacitor grounding |
| 汚染度 | 2 |
| 測定幅 | 10 mm0.394 in |
| 動作高度 | 2,000 m6,561.68 ftor less(Note)Do not use or store in an environment that has been pressurized to an air pressure higher than the atmospheric pressure at 0 m. |
| 最小検知物体 | ø0.5 mmø0.020 in(Installation distance: 500 mm19.685 in)(Note)When the light is blocked at the center position of 500 mm19.685 ininstallation distance. |
| 操作インジケーター | Emitter : Laser radiation indicator (Green)Receiver : Judgment output indicator (Orange / Green) |
| 適用可能なコントローラー | HG-TC101 (-P), HG-TC111 (-P), HG-TC113 |
| 設置距離 | 0 to 500 mm0 to 19.685 in |
| 規制遵守 | CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), FDA regulations |
| 位置検出方法 | CMOS-based |
| 温度特性 | ±0.03 % F.S./℃(Note)When the light is half-blocked at the center position of 100 mm3.937 ininstallation distance. |
| 環境耐性：保護 | IP67 (IEC) (Excluding connectors) |
| 耐環境性：周囲湿度 | 35 to 85 % RH, Storage: 35 to 85 % RH |
| 耐環境性：耐衝撃性 | 196 m/s2acceleration in X, Y and Z directions three times each |
| 耐環境性：周囲照度 | Incandescent light: 5,000 ℓx or less at the light-receiving face(Note)When the sampling cycle of the controller is set to "standard sampling". |
| 耐環境性：周囲温度 | -10 to +45 ℃+14 to +113 ℉(No dew condensation or icing allowed), Storage: -20 to +60 ℃-4 to +140 ℉ |
| 耐環境性：耐振動性 | 10 to 55 Hz frequency, 1.5 mm0.059 indouble amplitude in X, Y and Z directions for two hours each |
| 耐環境性：絶縁抵抗 | 20 MΩ or higher, using 250 V DC megger (between all terminals and case) |
製品説明
HG-T Laser Displacement Sensor. Narrow sensing head, no beam adjustment indicator, 10mm sensing array, 0 to 500mm sensing range, 1μm repeatability
