UHGTC101
UHGTC101 HG-TC101 PANASONIC HG-T Laser Displacement Sensor. High functionality master controller, NPN output
$0.00米ドル
4052 在庫あり
主な仕様
:When communication unitis connected
アイテム:Specifications
ケーブル:0.2 mm22-core (brown and blue lead wires) / 0.15 mm27-core composite cable, 2 m6.562 ftlong
詳細:Master unit / High performance type
サプライヤー情報
PANASONIC
製品: 4316
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| When communication unitis connected | |
| アイテム | Specifications |
| ケーブル | 0.2 mm22-core (brown and blue lead wires) / 0.15 mm27-core composite cable, 2 m6.562 ftlong |
| 詳細 | Master unit / High performance type |
| 製品 | Controller |
| 材料 | Case: Polycarbonate, Cover: Polycarbonate, Switches: Polyacetal |
| 正味重量 | 140 g approx. |
| 部品番号 | HG-TC101 |
| 1～7ユニット | 1 to 6 units |
| 製品名 | Thru-beam Type Digital Displacement Sensor HG-T |
| 8～15ユニット | 7 to 14 units |
| 表示範囲 | -199.999 to 199.999 mm-7.874 to 7.874 in |
| サンプリングレート | 1 ms (standard sampling) / 0.5 ms (high-speed sampling) |
| 製品番号 | HG-TC101 |
| 供給電圧 | 24 V DC ±10 %, including ripple 0.5 V (P-P) |
| 汚染度 | 2 |
| ディスプレイ解像度 | 1 μm0.039 mil |
| 動作高度 | 2,000 m6561.68 ftor less(Note) : Do not use or store in an environment that has been pressurized to an air pressure higher than the atmospheric pressure at 0 m. |
| 消費電流 | 100 mA or less (when sensor head is connected)(Note) : Current consumption does not include analog current output. |
| 規制遵守 | CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) |
| 適用センサーヘッド | HG-T1010、HG-T1110 |
| 外部入力切り替え | Input 1, Input 2, and Input 3 can be switched to "Preset / Reset / Trigger", "Bank Input A / Bank Input B / Select (Preset, Reset, Trigger)", or "Laser emission stop". |
| 外部出力切り替え | Output 1, Output 2, and Output 3 can be switched to 3-value, 2-value, Logic, and Logic 2. |
| 平均カウント（応答時間） | 1 time (2 ms), 2 times (3 ms), 4 times (5 ms), 8 times (9 ms), 16 times (17 ms), 32 times (33 ms), 64 times (65 ms), 128 times (129 ms), 256 times (257 ms), 512 times (513 ms), and 1,024 times (1,025 ms) switching type(Note) : Average count (response time) is for when the sampling cycle is set to 1 ms (standard sampling). Response times differ when the sampling cycle is set to 0.5 ms (high-speed sampling). |
| 接続されているスレーブユニットの数 | Maximum sink current and sourcecurrent of control output |
| 干渉防止機能 | Incorporated(Note) : This function operates for each set of 4 connected controllers. |
| 環境耐性：保護 | IP40(IEC) |
| アナログ出力：アナログ電流出力 | •Current output range: 4 to 20 mA/F.S. (default value)•Linearity: ±0.25 % F.S.•Output when alarm occurs: 0 mA•Load impedance: 250 Ω max.(Note) : Linearity is a value calculated from digitally measured values at F.S. = 16 mA for current output or F.S. = 4 V for voltage output. |
| アナログ出力：アナログ電圧出力 | •Voltage output range: 1 to 5 V/F.S. (default value)•Linearity: ±0.05 % F.S.•Output when alarm occurs: 5.2 V•Output impedance: 100 Ω max.(Note) : Linearity is a value calculated from digitally measured values at F.S. = 16 mA for current output or F.S. = 4 V for voltage output. |
| 外部入力（入力1、入力2、入力3） | Non-contact input or NPN open-collector transistor•Input conditionsInvalid: +8 V to +V DC or open, Valid: 0 to +1.2 V DC•Input impedance: 10 kΩ approx.Non-contact input or PNP open-collector transistor•Input conditionsInvalid: 0 to +0.6 V DC or open, Valid: +4 V to +V DC•Input impedance: 10 kΩ approx. |
| 接続可能なコントローラーの最大数 | Up to 15 slave units can be connected to a master unit.(Note) : When connected to a communication unit for digital displacement sensor, up to 14 slave units can be connected per master unit. |
| 耐環境性：周囲湿度 | 35 to 85 % RH, Storage: 35 to 85 % RH |
| 耐環境性：耐衝撃性 | 98m/s2acceleration (10 G approx.) in X, Y and Z directions five times each |
| 制御出力（出力1、出力2、出力3） | NPN open-collector transistor•Maximum sink current: 50 mA (Note)•Applied voltage: 30 V DC or less (between output and 0 V)•Residual voltage: 1.5 V or less (at 50 mA sink current)•Leakage current: 0.1 mA or lessPNP open-collector transistor•Maximum source current: 50 mA (Note)•Applied voltage: 30 V DC or less (between output and +V)•Residual voltage: 1.5 V or less (at 50 mA source current)•Leakage current: 0.1 mA or less(Note) : When slave units are connected to the master unit, the maximum sink current / source current of control output and ambient temperature vary depending on the number of connected slave units as shown below.Number of connected slave unitsMaximum sink current and sourcecurrent of control outputAmbient temperatureWhen communication unitis connected1 to 7 units1 to 6 units20 mA-10～+45℃+14 to +113 ℉8 to 15 units7 to 14 units10 mA |
| 耐環境性：周囲温度 | -10 to +50 ℃+14 to +122 ℉(No dew condensation or icing allowed) (Note), Storage: -20 to +60 ℃-4 to +140 ℉(Note) : When slave units are connected to the master unit, the maximum sink current / source current of control output and ambient temperature vary depending on the number of connected slave units as shown below.Number of connected slave unitsMaximum sink current and sourcecurrent of control outputAmbient temperatureWhen communication unitis connected1 to 7 units1 to 6 units20 mA-10～+45℃+14 to +113 ℉8 to 15 units7 to 14 units10 mA |
| 耐環境性：耐振動性 | 10 to 150 Hz frequency, 0.75 mm0.030 indouble amplitude (10 to 58 Hz), Maximum acceleration 49 m/s2(58 to 150 Hz) in X, Y and Z directions for two hours each |
| 耐環境性：絶縁抵抗 | 20 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure |
| 耐環境性：耐電圧性 | 1,000 V AC for one minute between all supply terminals connected together and enclosure |
| 外部入力（入力1、入力2、入力3）：入力時間 | • Trigger input: 2 ms or more (ON)• Laser emission stop input, preset input, reset input, bank input A/B(Note): 20 ms or more (ON)(Note) : Average count (response time) is for when the sampling cycle is set to 1 ms (standard sampling). Response times differ when the sampling cycle is set to 0.5 ms (high-speed sampling). |
| 制御出力（出力1、出力2、出力3）：警報出力 | Open when alarm occurs |
| 制御出力（出力1、出力2、出力3）：判定出力 | N.O. / N.C. switching type |
| 制御出力（出力1、出力2、出力3）：短絡保護 | Incorporated (automatic reset type) |
製品説明
HG-TC101_Controller_Thru-beam Type Digital Displacement Sensor HG-T_Master unit / High performance type
