在庫あり 注目商品
UHP-1000-48
UHP-1000-48 MEANWELL AC-DC Slim Single output enclosed power supply with PFC, Output 48VDC / 21A, Remote ON/..
$0.00米ドル
3424 在庫あり
主な仕様
名前（詳細）:UHP-1000-48
状態（詳細）:New
フォーマット（詳細）:Box
シリーズ（詳細）:UHP-1000
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | UHP-1000-48 |
| 状態（詳細） | New |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | UHP-1000 |
| 承認（詳細） | CE, EAC, TÜV, UL |
| 電力（W）（詳細） | 1.008,00 |
| サブフォーマット（詳細） | Or |
| 幅（mm）（詳細） | 115.00 |
| 高さ（mm）（詳細） | 41.00 |
| AC入力最大（詳細） | 264,00 |
| AC入力最小値（詳細） | 90,00 |
| アプリケーション（詳細） | Automation of Buildings, Appliances, Lighting, Industrial, Telecommunications |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | Power supply AC/DC |
| アイソレーション（V）（詳細） | 3.750,00 |
| 出力電圧（詳細） | 48,00 |
| ピーク電力（W）（詳細） | One thousand eight |
| 入力コネクタ（詳細） | Screw-Type |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 240.00 |
| 長い説明（詳細） | Switched Power supply in case of grid.Certified source for industrial applications, and home automation.Format in case of grid. U-type with low profile.Range of universal input90-264vac47-63Hz.Output voltage48vdc. Adjustable by potentiometer (48-57,6 Vcc).Output intensity21A. Range of output current of 0-21A according to demand load.Power:1008W.Efficiency typical:96%.Factor corrector, power>0,95to 230vac at full load.Protection against short circuit, over load, over voltage and temperature.Supports input surge 300Vca (5seg).Input class I with grounding.Relay contact DC-OK.LED indicator of operation.Operating altitude up to5000 metres.Working temperature: from-30ºCup+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:240 x 115 x 41.5 years warranty.Manufacturer: MEAN WELLThe series UHP are switching power supplies grid-type, U-shape and low profile with high efficiency.Support input voltages of 300Vca for 5 seconds and use components of the highest reliability. Support peak loads of up to 150%, during 100ms, which allows you to start heavy loads or withstand spikes without the need to oversize the power source. Have a power LED. Are certified to operate up to 5000 meters of altitude. Have multiple protections (short circuit, overload, over voltage and temperature). Designed for multiple applications such as mechanical and electrical equipment, appliances, LED panels, industrial machinery, control of industrial systems. Are certified CE, UL, EAC, and with standards for residential use EN60335-1 and are designed to comply with EN61558-1, EN60335, TUV EN62368-1 and UL62368-1.This series, is one of the best options for sources of high power (1000W). Its high reliability and robustness, making them suitable for all types of environments. Its unique design, no fan and semi-encapsulated, with gel of silicone of first quality, offers greater protection against dust and moisture. The design without fan, you can solve the problems of noise level, so that the series UHP, it is extremely suitable for environments that require an absolute tranquility.The series UHP these sources are robust and reliable for all types of applications. |
| 出力コネクタ（詳細） | Screw-Type |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | Taiwan |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Switched Power supply in case of grid.
製品資料
データシート
技術仕様と性能データ
ユーザーマニュアル
設置・操作ガイド
