UHP-350R-3.3
UHP-350R-3.3 MEANWELL AC-DC Slim Single output enclosed power supply with PFC, Output 3.3VDC / 60A, DC OK si..
$0.00米ドル
4078 在庫あり
主な仕様
名前（詳細）:UHP-350R-3.3
状態（詳細）:New
フォーマット（詳細）:Box
シリーズ（詳細）:UHP-350R
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | UHP-350R-3.3 |
| 状態（詳細） | New |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | UHP-350R |
| 承認（詳細） | CCC, CE, EAC, UL |
| 電力（W）（詳細） | 198,00 |
| サブフォーマット（詳細） | Or |
| 幅（mm）（詳細） | 62.00 |
| 高さ（mm）（詳細） | 31.00 |
| AC入力最大（詳細） | 264,00 |
| AC入力最小値（詳細） | 90,00 |
| アプリケーション（詳細） | Automation of Buildings, Appliances, Lighting, Industrial, Telecommunications |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | Power supply AC/DC |
| アイソレーション（V）（詳細） | 3.750,00 |
| 出力電圧（詳細） | 3,30 |
| ピーク電力（W）（詳細） | One hundred ninety eight |
| 入力コネクタ（詳細） | Screw-Type |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 220.00 |
| 長い説明（詳細） | Redundant Power supply in case of grid.Certified source for industrial applications, and home automation.Format in case of grid. U-type with low profile.Range of universal input90-264vac47-63Hz.Output voltage3.3 Vdc. Adjustable by potentiometer (3,2-3,5 Vcc).Output intensity60A. Range of output current 0-60A according to demand load.Power:198W.Efficiency typical:88.5 per cent.Factor corrector, power>0,94to 230vac at full load.Protection against short circuit, over load, over voltage and temperature.Input class I with grounding.LED indicator of operation.Active signal DC-OK by optocoupler.Paralelizable for redundancy and to increase power.Operating altitude up to5000 metres.Working temperature: from-30ºCup+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:220 x 62 x 31.3 years warranty.Manufacturer: MEAN WELLThe series UHP are switching power supplies grid-type, U-shape and low profile with high efficiency.Support input voltages of 300Vca for 5 seconds and use components of the highest reliability. Support peak loads of up to 150%, during 100ms, which allows you to start heavy loads or withstand spikes without the need to oversize the power source. Have a power LED. Are certified to operate up to 5000 meters of altitude. Have multiple protections (short circuit, overload, over voltage and temperature). Designed for multiple applications such as mechanical and electrical equipment, appliances, LED panels, industrial machinery, control of industrial systems. Are certified CE, UL, CAS, CCC and regulations for residential use EN60335-1 and are designed to comply with EN61558-1-2 and EN61558-2-16. Its design semiencapsulado to provide greater protection against dust and moisture.This version UHP-200R includes a function of redundancy, so that we can connect two sources in parallel. When in parallel operation, the maximum load should not be greater than the nominal power of the sources used. They also have an active signal DC-OK by using optocouplerThe series UHP these sources are robust and reliable for all types of applications. |
| 出力コネクタ（詳細） | Screw-Type |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 3,00 |
| 原産国（詳細） | China |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
Redundant Power supply in case of grid.
