X-10GQ-B

General-purpose Basic SwitchXDirect Current Switch with Built-in MagneticBlowout• Incorporates a small permanent magnet in the contact mecha- nism to deflect the arc to effectively extinguish it.• Same shape and mounting procedures as the Z Basic Switch- es.Model Number Structure■ Model Number LegendX-10G @[email protected]: 10 A (125 VDC)2.Contact GapG:0.9 mm3.ActuatorNone: Pin plungerD:Short spring plunger S:Slim spring plunger Q:Panel mount plungerQ21:Panel mount cross roller plungerQ22:Panel mount roller plungerL: Leaf springW: Hinge leverW2: Hinge roller leverW21: Short hinge leverW22: Short hinge roller lever W4: Low-force hinge lever M:Reverse hinge leverM2:Reverse hinge roller leverM22:Reverse short hinge roller lever4.TerminalsNone: Solder terminalB:Screw terminal (with toothed washer)General-purpose Basic Switch X F-149
