在庫あり 注目商品
XLG-25-A
XLG-25-A MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 22-54VDC / 0...
$0.00米ドル
3764 在庫あり
主な仕様
名前（詳細）:XLG-25-A
状態（詳細）:New
フォーマット（詳細）:Box
シリーズ（詳細）:XLG-25-A
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | XLG-25-A |
| 状態（詳細） | New |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | XLG-25-A |
| 承認（詳細） | CCC, CE, ENEC, MM, RCM, UL |
| 電力（W）（詳細） | 25,00 |
| サブフォーマット（詳細） | IP67 |
| 幅（mm）（詳細） | 63.00 |
| 高さ（mm）（詳細） | 30.00 |
| AC入力最大（詳細） | 305,00 |
| AC入力最小値（詳細） | 90,00 |
| アプリケーション（詳細） | Lighting, Industrial |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | LED Driver |
| アイソレーション（V）（詳細） | 3.750,00 |
| ピーク電力（W）（詳細） | Twenty five |
| 入力コネクタ（詳細） | Cable |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 105.00 |
| 長い説明（詳細） | LED driver with constant power output.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range90-305Vca47-63Hz.Output in constant current700mA.Adjustable by external potentiometer (250-1050mA).Range of output voltage with current mode constant22 to 54Vccaccording to demand load and according to adjustment of the output current.Power:25W.Efficiency typical:88%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current between 250 and 1050mA.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature, input voltage high and output voltage.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):105 x 63 x 30mm.5 years of warranty.Manufacturer: MEAN WELL.VIDEO VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.In this version, the output current can be adjusted byknob that incorporates the source itself.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67. The series XLG has a high efficiency designed for port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting.Approved HL Class I Division 2 for ex-zones in the US. |
| 出力コネクタ（詳細） | Cable |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | China |
| 出力電流 mA (詳細) | 250, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000, 1050 |
| 最小出力強度（mA）（詳細） | 250,00 |
| 出力最大強度（mA）（詳細） | 1.050,00 |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver with constant power output.
