XLG-75-24
XLG-75-24 MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 24VDC / 3.1A..
$0.00米ドル
4897 在庫あり
主な仕様
名前（詳細）:XLG-75-24-TO
状態（詳細）:New
在庫（詳細）:Yes
フォーマット（詳細）:Box
サプライヤー情報
MEANWELL
製品: 6448
通常、2〜3営業日以内に出荷します
品質保証済み
高速配送
テクニカルサポート
技術仕様
| パラメータ | 価値 |
|---|---|
| 名前（詳細） | XLG-75-24-TO |
| 状態（詳細） | New |
| 在庫（詳細） | Yes |
| フォーマット（詳細） | Box |
| シリーズ（詳細） | XLG-75-12/24-TO |
| 承認（詳細） | CCC, CE, EAC, ENEC, MM, RCM, UL |
| 電力（W）（詳細） | 74,40 |
| サブフォーマット（詳細） | IP67 |
| 幅（mm）（詳細） | 63.00 |
| 高さ（mm）（詳細） | 32.00 |
| AC入力最大（詳細） | 305,00 |
| AC入力最小値（詳細） | 100,00 |
| アプリケーション（詳細） | Lighting |
| メーカー（詳細） | MEAN WELL |
| 製品タイプ（詳細） | LED Driver |
| アイソレーション（V）（詳細） | 4.200,00 |
| 出力電圧（詳細） | 24,00 |
| ピーク電力（W）（詳細） | 74.4 |
| 入力コネクタ（詳細） | Cable |
| 入力周波数（詳細） | 50 Hz, 60 Hz |
| ロング/背景（詳細） | 140.00 |
| 長い説明（詳細） | LED driver with constant power output.Specially designed to feed LED strips.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output voltage24vdc.Range of output voltage(16,8-24vdc).Output intensity3.1. Adjustable via integrated potentiometer (1,55-3.1 A).Power:Are 74.4 W.Efficiency typical:90%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current between 1.55 and 3.1 A.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature and output voltage.Approved HL Class I Division 2 for ex-zones in the US.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):140 x 63 x 32mm.5 years of warranty.Manufacturer: MEAN WELL.VIDEO VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Working mode constant voltage giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.You can also work in mode constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. In this version, the output current can be adjusted byknob that incorporates the source itself.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67, the series XLG has a high efficiency of up to 94.5%, and surge protection (6kV / 4kV and 10kV optional) according to the regulations EN61547 and EN61000-4-5, suitable for any application of outdoor luminaires.These sources are suitable for projects of general lighting in indoor and outdoor, including strips light waterproof / advertising panels, or sources of tension with DMX control, port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting. Approved HL Class I Division 2 for ex-zones in the US. |
| 出力コネクタ（詳細） | Cable |
| 入国の種類 CA (詳細) | Single-phase |
| 保証期間（年数）（詳細） | 5,00 |
| 原産国（詳細） | China |
製品説明
More details
主な機能
- 産業グレードの品質
- RoHS準拠
- CE認証取得
- 1年保証
技術的詳細
LED driver with constant power output.
