F3S-TGR-NMPR-21-M1J8-R

Magnetic Non-contact Safety SwitchesF3S-TGR-N@RReed non-contact switches monitor the status of guarding doors. Stainless steel housing for high hygiene demands in the food industry are available.• Based on reed technology• Connect up to 6 switches in series• Operates with all Omron safety controllers• Operates behind stainless steel fittings• Non-contact – no abrasion – no particles• Compensation of mechanical tolerances• Suitable for high pressure cleaning, CIP/SIPprocesses due IP69K (pre-wired types)• Conforms to safety categories up PLe acc. EN ISO13849-1Model Number StructureF3S-TGR-N@@R-@@-@@1 2 3 41.TypeL:Elongated SensorS:Small SensorM: Miniature Sensor C:Compact Sensor W: Wide SensorB:Barell Sensor2.Housing MaterialP:Plastic HousingM: Stainless Steel HousingH:Hygienic designed Stainless Steel HousingF:Special Food Type Stainless Steel Housing3.Contact configuration11*: 1 Normally Closed Contact (NC) +1 Normally Open Contact (NO)20*: 2 Normally Closed Contacts (NC)21:2 Normally Closed Contacts (NC) +1 Normally Open Contact (NO)* only existing for some NMPR-types4.Cable Length/connection05:5 m Cable05-R*: 5 m Cable exit to the right10:10 m Cable10-R*: 10 m Cable, exit to the rightM1J8: M12 male connector, 8 pin, fitted with 250 mm cableM1J8-R*:M12 male connector, 8 pin, fitted with 250 mm cable exit to the right08-10**:M8 male connector, 4 pin08-10-R**: M8 male connector, 4 pin, exit to the right* only for F3S-TGR-NMPR and F3S-TGR-NMHR** only for F3S-TGR-NMPR1
